>> Timeless material meets - limitless technology
Metal 3D Printing holds a unique position in modern-day product development. It allows for the direct manufacturing of complex end-use parts and facilitates tooling for conventional manufacturing technologies, reducing costs and lead times. This technology is also known as Direct Metal Laser Sintering (DMLS) and Selective Laser Melting (SLM).
>> Why choose Metal 3D Printing?
This technology combines the design flexibility of 3D Printing with the mechanical properties of metal. From tooling inserts with cooling channels to lightweight structures for aerospace, any application that involves complex metal parts potentially benefits from Metal 3D Printing.
>> Ideal applications for Metal 3D Printing
● Fully functional prototypes ● Production tools ● Tooling such as molds and inserts ● Rigid housings
● Ductwork ● Spare parts ● Heat exchangers and heatsinks
>> Standard
The all-rounder ● It's all about the technology ● Industry-standard quality requirements ● Ideal for prototypes and simple end-parts ● Form-, fit- and function-testing ● Strength and density similar to cast parts
>> Performance
The specialist For complex production ● Ideal for complex metal parts designed for AM ● Applications in demanding environments ● Suited for series production ● Strength and density more performant than casting ● Specialized quality test reports available to your specification
>> Technical Specifications

   Standard lead time

   Minimum of 10 working days, depending on part size, number of components and finishing degrees

   Standard accuracy

   In accordance with DCTG 8 of DIN EN ISO 8062-3: 2008-09 for dimensions between 30 and 400 mm,
   DTTG 6 for dimensions below 30 mm and DIN ISO 2768 -1 g (rough) for dimensions between 3 mm and 400mm.
   (for more details and IT grades have a look at the
design guidelines)

   Layer thickness

   AlSi10Mg: 0.03 – 0.1 mm
   Ti6Al4V: 0.03 – 0.06 mm
   SS316L: 0.03 – 0.1 mm
   IN718: 0.03 – 0.1 mm

   Minimum wall thickness

   1 mm (standard grade) / 0.5 mm (performance grade and inconel)

   Maximum build dimensions

   Dimensions are unlimited as components may be composed of several sub-parts.
   The maximum build envelope is 500 x 280 x 315 mm

   Surface structure

   Unfinished parts typically have a rough surface but various finishing degrees can achieve smooth surfaces

>> Aluminum (AlSi10Mg)
● Good strength and thermal properties with low weight ● Flexible post-processing possibilities ● Lead time: 10 working days ● Maximum part dimensions: 500 x 280 x 315 mm
>> Stainless steel (SS316L)
● Excellent strength, high ductility & good thermal properties ● Highly corrosion-resistant ● Lead time: 10 working days ● Maximum part dimensions: 250 x 250 x 280 mm
